Brightness: 18,000 ANSI lumens, 20,000 center lumensContrast: 1600-2000:1 full field | 650:1 ANSIUniformity: 80% brightness uniformity
Display
Type: 3-chip 0.95” DMDNative resolution: HD (1920 x 1080)
Lamp
Type: 3.0kW Xenon bubble lamp moduleLife:750 hours typical lamp life
Input
Standard
AnalogDual link DVISD/HD-SDIVideo Decoder
Optional
AnalogDual link DVISD/HD-SDIVideo DecoderTwin HDMI
Signals
HDTV formats VGA through to QXGA (2048 x 1536)Accepts all current HDTV/DTV formatsMulti-standard video decoderHorizontal and vertical scaling, all inputs
Pixel clock
165 MHz
Scan rates
15 kHz to 120 kHz Horizontal23.97 Hz to 150 Hz Vertical
Control and networking
RS232 In/OutRS422 InEthernet (10/100)USB DeviceGPIO (RS232 9 Pin male connector)Built-in, backlit LCD keypadRemote control (with optional wired XLR connection)
Lens options
Fixed
ILS Lens 0.73:1 SX+ / 0.67:1 HD*ILS Lens 1.2:1 SX+ / 1.1:1 HD
3.0kW Xenon lamp3.0kW Xenon lamp bare bulb kitBulb alignment toolAnalog input cardDual link DVI input cardVideo decoder input cardDual SD/HD-SDI input cardTwin HDMI input cardDMX512 interface cardILS lens adapter kitFog juice filtersEdge-blending kitRemote IR sensor3D upgrade kitChristie AutoStack⑩
Enhanced feature sets
3D upgradableEmbedded Christie Twist⑩Embedded image tilingIntelligent Lens System (ILS)Liquid coolingAdvanced block artifact reductionChristieNET ⑩ Web interfaceUser-friendly, intuitive LCD keypadAdvanced Loop-Thru twin HDMI cardSet-up lightsLamp memory moduleUser replaceable lampsAdvanced, 10-bit processingAutomatic shut off and ECO modeDust-sealed light engineSNMP (simple network management protocol)DHCP (dynamic host configuration protocol)Hybrid stackCompatibility with legacy accessories
Power requirements
Operating voltage: 200 VAC to 240 VAC @ 50/60 HzMax current: 20 A @200VMax power: 4000 WDissipation: 13,650 BTU/hr
Dimensions
Dimensions: (L x W x H): 32.0 x 24.5 x 16.5" (815 x 621 x 419mm)Shipping dimensions: (L x W x H): 41.0 x 32.5 x 29.5" (1041 x 825 x 749mm)Weight: 160 lb (72.5 kg) (without lens)Shipping weight: 200 lb (91 kg)
Operating environment
Temp: 40 to 104∑ (5 to 40∑ C)Humidity: 20 - 80% noncondensing
Regulatory
Directives (EC) 2002/95/EC (RoHS); 2002/96/EC (WEEE)Regulation (EC) No. 1907/2006 (REACH); CAN/CSA C22.2 No. 60950-1; UL 60950-1; IEC 60950-1; FCC, Part 15, Subpart B, Class A; EN55022/CISPR22 Class A; EN55024 / CISPR24Certifications marks: - cULus (Canada and US) - CE (EU) - CCC (China) - GoST-R (Russia) - KC (Korea) - PSE (Japan) - C-Tick (Aus, tralia & New Zealand) - South Africa
Limited warranty
Three years parts and labor (including light engine)
