| 是否进口 | 否 |
|---|---|
| 热熔胶类型 | 压敏热熔胶 |
| 固化方式 | 热固化 |
| 有效期 | 6个月 |
| 功能 | 组装封边，气孔封口 |
| 用途范围 | 继电器 |
| 包装 | 瓶装 |
| 保质期 | 6个月 |
| 参考用量 | 12 |
| 产地 | 东莞 |
| 产品等级 | 优级品 |
| 工作温度 | 100-120摄氏度60分钟 |
| 供货地 | 华南地区 |
| 固体份含量 | 70.0 |
| 认证 | ROHS |
| 粘度 | 25000（Pa·s） |
| 贮存 | 常温 |
| 执行质量标准 | 国标 |
| 有效物质≥ | 1.0 |
| 粘合材料类型 | 电子元件 |
| 品牌 | 依美 |
| 型号 | 380系列 |
| 产品上市时间 | 2006 |
Engineered Conductive Materials, LLC Technical Data Sheet
An Engineered Materials Systems, Inc. Company
EC-9519
132 Johnson Drive
Delaware,Ohio 43015-8699 UV Curable Encapsulant
Tel: (740) 362-4444
Fax: (740) 362-4433
www.conductives.com
| DEION | EC-9519is a UV curable surface mount device encapsulant.EC-9519is usually syringe applied over surface mount devices to help prevent surface migration and to offer physical protection.EC-9519offers good adhesion & holding properties to most rigid & flexible substrates. |
| ADVANTAGES | ü Excellent adhesion ü Superior flexibility
| ü No dilution required ü Fast curing
|
| TYPICAL UNCURED PROPERTIES | Color Viscosity Total Solids Content Density Flash Point VOC
| Clear 4,000 CPS @ 25° C. 100 % 9.6 lbs/gallon 212oF (100oC) Tag Close Cup 0
|
| TYPICAL CURED PROPERTIES | Hardness TemperatureRange
| 50 Shore D -40oC to 120oC |
EC-9519
TDS
Page 2
| APPLICATION INFORMATION | EC-9519is usually applied by the use of a hand syringe or an automatic applicator.
|
| CURE SCHEDULE | EC-9519The minimum cure energy recommended is 750 Millijoules per square centimeter.Complete cure can be confirmed by a crosshatch adhesion test. |
| CLEAN UP | EC-9519can be cleaned up with M.E.K (Methyl Ethyl Ketone) or any blend of solvents that will completely remove a cured film. |
| STORAGE AND HANDLING | Shelf life is twelve (12) months in an unopened container, stored below 70oF. Avoid exposure to direct sunlight. Avoid high temperature exposure. |
| HEALTH AND SAFETY | Use with adequate ventilation. Avoid skin contact. If ingested, consult a physician immediately. Consult the product Material Safety Data Sheet for additional information. |
| APPLICATION ASSISTANCE | ECM’s application specialists are available to assist you in production start-up withEC-9519. For more information, please call ECM at 1.740.362.4444. |
(6-04, EC-9519, TZ, Rev 0)
